BPP Polymer Modified Bitumen Insulation Membrane

BPP Polymer Modified Bitumen Membrane is a high-quality waterproofing and insulation solution engineered for reliable performance across a wide range of building applications. This membrane is manufactured using polymer-modified bitumen enhanced with APP (Atactic Polypropylene) and reinforced with glass fiber mats and non-woven polyester layers to ensure strength, stability, and durability.

Designed in accordance with recognized national standards, BPP membranes provide effective protection against moisture penetration while maintaining excellent mechanical properties.

What Is BPP Polymer Modified Bitumen Membrane?

BPP is a prefabricated bituminous insulation membrane developed through a specialized polymer formulation. The integration of APP-modified bitumen improves thermal stability and flexibility, while multi-layer reinforcements enhance resistance to tearing, deformation, and fatigue.

Supplied in roll form, BPP membranes are suitable for both concealed and exposed insulation systems.

Available Types

BPP Polymer Modified Bitumen Membrane is produced in two main variants:

  • Standard Type:
    Suitable for surfaces that will be fully covered after installation, such as under tiles, screeds, or protective layers.

  • Aluminum Foil–Faced Type:
    Designed for exposed applications where the insulation layer remains uncovered. The aluminum surface reflects UV radiation and significantly reduces unwanted thermal absorption.

Applications

BPP membranes are widely used for insulation and waterproofing of:

  • Flat and sloped roofs

  • Kitchens and sanitary areas

  • Bathrooms and wet rooms

  • Building foundations

  • Swimming pools and fountains

They can be applied on various substrates, including concrete, metal, stone, and brick surfaces.

Installation & Surface Preparation

  • All surfaces must be completely dry prior to installation to ensure proper adhesion.

  • Moisture trapped beneath the membrane may reduce bonding strength and performance.

  • If construction activities continue after installation, insulated surfaces should be adequately protected to prevent damage.

Storage Guidelines

  • Membrane rolls should be stored upright on a flat surface.

  • Keep away from direct sunlight and heat sources.

  • Rolls should be placed next to each other without excessive pressure.

Compliance & Standard

This product is manufactured in compliance with Iran National Standard No. 3885-3, issued by the Iran Institute of Standards and Industrial Research, covering quality control requirements for roofing and insulating membranes.

Technical Specifications

Parameter Unit Value
Nominal Length m 10
Nominal Width m 1
Nominal Thickness mm 4 ± 0.2
Mass per Unit Area kg/m² 4.1 ± 0.2
Water Permeability (min) kPa 60
Heat Stability (Cool Climate) °C 100
Cold Flexibility (Cool Climate) °C +5
Cold Flexibility (Tropical Climate) °C 0
Water Absorption (Max) % 1
Tear Resistance (Longitudinal) kgf 12
Tear Resistance (Transverse) kgf 12

Why Choose BPP Polymer Modified Bitumen Membrane?

BPP membranes offer a balanced combination of waterproofing efficiency, thermal resistance, and mechanical durability. Their adaptability to different surfaces and environments makes them a dependable choice for residential, commercial, and industrial insulation projects.
